Audio and Control Cables
Belden’s wide array of audio cables range from high-performance, lowcapacitance
and digital audio types for optimum signal delivery, to cables
manufactured to basic industry specifications for commercial use, short
runs and non-mission critical applications. Belden pioneered the Easy Strip
foil bonded to the jacket for ease of installation and now offers this feature on
digital cables, plenum cables and 2-pair versions. Many cables are suitable for
RS-422 and RS-485 applications. Consult the Belden Catalog for a full listing.

Audio, Video, and Control Cables
Belden offers standard cables and custom combinations designed for use
in a wide range of A/V and control applications, including products for:
faceplates for presentation projection, control systems, touch panels, sharing
of touch panels, sharing of local sources, control of multiple sources
through switches and remote Web browser controls, multiple media
runs, bi-directional audio, and audio/video distribution.

音頻和控制電纜
Belden的音頻電纜廣泛的範圍從高性能，lowcapacitance
最佳的信號傳遞到電纜和數字音頻類型
用於商業用途的基本行業規範生產，短
奔跑和非關鍵任務的應用程序。百通率先推出了易地帶
箔粘合外套，便於安裝，現在提供此功能
數字電纜，阻燃電纜和2對版本。許多電纜都適合
RS-422和RS-485應用。一個完整的上市諮詢百通目錄。
　

音頻，視頻和控制電纜
百通提供設計用於標準電纜和自定義組合
在廣泛的A / V和控制應用，產品包括：
面板演示投影，控制系統，觸摸屏，分享
觸摸屏，本地資源共享，多源的控制
通過交換機Web瀏覽器和遠程控制，多種媒體
運行，雙向音頻，音頻/視頻分佈。

2/C Shielded Audio & Control Cables — Non-plenum
Belden Part No. Description
5660FT 1 STP 24 AWG solid TC, Low Cap FPE,
FS + TC DW PVC, CMR 100-ohm Low Cap
1883A 1 STP 24 AWG 31 pF/ft, FS,
24 AWG DW PP/PVC, CMR Available in 8 colors
5500FE 1 STP 22 AWG BC,
FS + TC DW TP/PVC, CMR Security grade
1503A 1 STP 22 AWG TC, 53 pF/ft, FS, PVC Insulation,
24 AWG TC DW PVC/PVC, CM flexible jacket
1266A 1 STP 22 AWG 30 pF/ft, FS,
24 AWG DW PP/PVC, CM Flexible and CM
9451 1 STP 22 AWG 35 pF/ft, FS,
22 AWG DW PP/SR-PVC, CMR EZ foil strips with jacket
8451 1 STP 22 AWG 34 pF/ft, FS,
22 AWG DW paper, PP/SR-PVC, CMR Paper; easy jacket strip
8761 1 STP 22 AWG 24 pF/ft, FS,
22 AWG DW PE/PVC, CM PE Insulation, Low Cap
9461 1 STP 22 AWG 24 pF/ft, FS,
22 AWG DW PE/PVC, CM PE Insulation, Low Cap
5540FT 1 STP 22 AWG str. TC, Low Cap FPE, Brown jacket
FS + TC DW PVC, CMR 100-ohm Low Cap
5520FE1 STP 22 AWG solid BC FS,
24 AWG DW PP/PVC, CMR Solid conductors
8450 1 STP 22 AWG solid TC 40 pF/ft, FS,
22 AWG solid DW PP/PVC, CM Solid conductors
5400FE 1 STP 20 AWG BC, 56 pF/ft,
FS + TC DW TP/PVC, CMR Security grade
8762 1 STP 20 AWG 27 pF/ft, FS,
20 AWG DW PE/PVC, CM PE Insulation
5300FE 1 STP 18 AWG BC, 65 pF/ft,
FS+ TC DW TP/PVC, CMR Security grade
5340FT 1 STP 18 AWG str. TC, Low Cap FPE,
FS + TC DW PVC, CMR 100-ohm Low Cap FFEP
8760 1 STP 18 AWG 30 pF/ft, FS, Low Capacitance,
20 AWG DW PE/PVC, CM PE Insulation, Top seller
5200FE 1 STP 16 AWG BC, 76 pF/ft,
FS + TC DW TP/PVC, CMR Security grade
87191 STP 16 AWG 23 pF/ft, FS, Low Capacitance,
18 AWG DW PE/PVC, CM / CL2 PE Insulation
5100FE 1 STP 14 AWG BC, 83 pF/ft, Security grade,
FS + TC DW TP/PVC, CL3R CL3R and FPLR
87201 STP 14 AWG 24 pF/ft, FS, Low Capacitance,
16 AWG DW PE/PVC, CL2 PE Insulation
5000FE 1 STP 12 AWG BC, 83 pF/ft, Security grade,
FS + TC DW TP/PVC, CL3R CL3R and FPLR
8718 1 STP 12 AWG 25 pF/ft, FS, Low Capacitance,
14 AWG DW PE/PVC, CL2 PE Insulation

2/C Shielded Audio & Control Cables — Plenum
Belden Part No. Description
6660FT 1 STP 24 AWG solid TC, Low Cap FFEP, Brown Jacket,
FS + TC DW LS-PVC, CMP 100-ohm Low Cap FFEP
6500FE 1 STP 22 AWG BC, 55 pF/ft, Security grade,
FS + TC DW LSPVC/LSPVC, CMP LS-PVC Insulation
6540FT 1 STP 22 AWG str TC, Low Cap FFEP, Brown jacket,
FS + TC DW LS-PVC, CMP 100-ohm Low Cap FFEP
6500FC 1 STP 22 AWG BC FEP Insulation,
FS + DW FEP Insulation, CMP Bare Copper; 45 pF/ft.
9451P 1 STP 22 AWG 35 pF/ft, FS + TC DW,
FEP Insulation, CMP Foil strips with jacket, colors
82761 1 STP 22 AWG 35 pF/ft, FS + TC DW, Easy jacket strip, Heavy-duty,
FEP Insulation, CMP Low Capacitance
87761 1 STP 22 AWG 35 pF/ft, FS + TC DW,
FEP Insulation, red PVDF Jacket, CMP Plenum-rated use, 150º C
88761 1 STP 22 AWG 35 pF/ft, FS + TC DW,
FEP Insulation, red FEP Jacket, CMP Plenum-rated, 200º C
6400FE 1 STP 20 AWG BC, 56 pF/ft, Security grade
FS + TC DW, CMP LS-PVC Insulation
6400FC 1 STP 20 AWG BC, FEP insulation
FS + TC DW, CMP FEP Insulation
6300FE1 STP 18 AWG BC, 70 pF/ft, Security grade
FS + TC DW, CMP LS-PVC Insulation
6340FT 1 STP 18 AWG str. TC, Low Cap FFEP,
FS + TC DW LS-PVC, CMP 100-ohm Low Cap FFEP
6300FC1 STP 18 AWG BC FEP Insulation,
FS + DW FEP Insulation, CMP FEP Insulation
827601 STP 18 AWG TC 51 pF/ft, FS,
20 AWG TC DW, FEP Insulation, CMP Tinned Copper; Mid Cap
6200FE 1 STP 16 AWG BC, 81.5 pF/ft, FS,
18 AWG TC DW, CMP LS-PVC Insulation
6100FE1 STP 14 AWG BC, 85 pF/ft, FS,
16 AWG TC DW CL2P LS-PVC Insulation
6000FE1 STP 12 AWG BC, 97 pF/ft, FS,
16 AWG TC DW CL2P LS-PVC Insulation

Control & Audio Cables, Multi-Conductor/Multi-Pair -
Non-plenum
22 AWG Shielded
Belden Part No. Description
5501FE 3/C 22 AWG Shielded, CMR
5502FE 4/C 22 AWG Shielded, CMR
5504FE 6/C 22 AWG Shielded, CMR
5506FE 8/C 22 AWG Shielded, CMR
5508FE 10/C 22 AWG Shielded, CMR
8723 2 STP 22 AWG TC, CM (2 pr OAS = 5541FE)
8777 3 STP 22 AWG TC, CM (3 pr OAS = 5542FE)
5543PE 4 STP 22 AWG BC, CMR (4 pr OAS = 5543FE)
87786 STP 22 AWG TC, CM (6 pr OAS = 5545FE)
1818R 12 STP 22 AWG, Individual Pair Jackets, Snake, CMR
　

18 AWG Shielded
Belden Part No. Description
5301FE 3/C 18 AWG Shielded, CMR
5302FE 4/C 18 AWG Shielded, CMR
5304FE 6/C 18 AWG Shielded, CMR
5306FE 8/C 18 AWG Shielded, CMR
5307FE 9/C 18 AWG Shielded, CMR
5341FE2 TP 18 AWG O/A Shielded, CMR
5342FE 3 TP 18 AWG O/A Shielded, CMR
5343FE 4 TP 18 AWG O/A Shielded, CMR
5345FE 6 TP 18 AWG O/A Shielded, CMR
　

Control & Audio Cables, Multi-Conductor/Multi-Pair -
Plenum
22 AWG Shielded
Belden Part No. Description
6501FE 3/C 22 AWG Shielded, CMP
6502FE 4/C 22 AWG Shielded, CMP
6504FE 6/C 22 AWG Shielded, CMP
6506FE 8/C 22 AWG Shielded, CMP
6508FE 10/C 22 AWG Shielded, CMP
1325A 2 STP 22 AWG, CMP (2 pr OAS = 6541FE)
1326A 3 STP 22 AWG, CMP (3 pr OAS = 6542FE)
6543PA 4 STP 22 AWG, CMP (4 pr OAS = 6543FE)
6545PA 6 STP 22 AWG, CMP (6 pr OAS = 6545FE)
6548PA 12 STP 22 AWG, CMP
　

20 AWG Shielded
Belden Part No. Description
6401FE 3/C 20 AWG Shielded, CMP (Non-plenum = 5401FE)
6402FE 4/C 20 AWG Shielded, CMP (Non-plenum = 5402FE)
6441FE 2 pr 20 AWG OAS, CMP (Non-plenum = 5441FE)
6443FE 4 pr 20 AWG OAS, CMP
　

18 AWG Shielded
Belden Part No. Description
6301FE 3/C 18 AWG Shielded, CMP
6302FE 4/C 18 AWG Shielded, CMP
6304FE 6/C 18 AWG Shielded, CMP
6306FE 8/C 18 AWG Shielded, CMP
6307FE 9/C 18 AWG Shielded, CMP
6309FE 12/C 18 AWG Shielded, CMP
6341PC 2 STP 18 AWG, CMP (2 pr OAS = 6341FE)
6342PC 3 STP 18 AWG, CMP (3 pr OAS = 6342FE)
6343PC 4 STP 18 AWG, CMP (4 pr OAS = 6343FE)
belden 6345PC 6 STP 18 AWG, CMP (6 pr OAS = 6345FE)
　

Commercial Automation & Lighting Control - Plenum
Belden Part No. Description
1502P 1 STP 22 AWG data, plus 2/C 18 power (Axlink™ type)
belden 82841 1 pair DMX, 24 AWG
82842 2 pair DMX, 24 AWG
BC = Bare Copper • O/A Shield = Overall Shield • OAS = Overall Shield • PP = Polypropylene • STP =
Shielded Twisted Pair • TC = Tinned Copper • TP = Twisted Pair
　

Belden offers several other cable types for all installations.
AXlink™ is a trademark of AMX
Commercial Automation & Lighting Control - Non-plenum
Belden Part No. Description
1502R 1 STP 22 AWG data, plus 2/C 18 power (AXlink™ type)
9841 1 pair DMX, 24 AWG
3105A1 pair DMX, 22 AWG
9842 2 pair DMX, 24 AWG
belden 3107A 2 pair DMX, 22
